Accessories – GROWATT – switch – SYN-50-XH-10
SKU: F2G1B50
EAN: 2010000043295
Product details
SYN 50-XH-10
SYN 50-XH-10 is a backup power device designed to work with MIN-XH series inverters. It provides 6000 W of continuous backup power and switches over in less than 500 ms after grid disconnection. An integrated circuit breaker and energy meter simplify installation.
Key advantages of SYN 50-XH-10
- Backup power: continuous power of 6000 W and peak power of 6600 W for less than 10 s.
- Quick switching: switching time after grid disconnection below 500 ms.
- Integrated equipment: circuit breaker, imported and exported energy meter with 1% accuracy, and manual bypass switch.
- RS485 communication: communication interface specified in the device specifications.
- Cooling by natural convection: noise level below 30 dB.
- IP65 protection rating: operating temperature range from -40 to 60 °C and wall mounting.
Who is this a good choice for?
SYN 50-XH-10 is designed for users of systems with MIN-XH series inverters who need backup power with a continuous output of up to 6 kW. This solution is for those who also require measurement of imported and exported energy and the ability to switch the bypass manually.
Datasheet Growatt SYN-50-XH-10
Growatt-SYN-50-XH-10-Datasheet.pdf
| Parameter | Value |
|---|---|
| AC input data | |
| Maximum AC input overcurrent protection current (A) | 63 |
| Maximum continuous input current (A) | 50 |
| AC output data | |
| Nominal AC output voltage (V) | 230 |
| AC output voltage range (V) | 180-270 |
| Nominal AC frequency (Hz) | 50/60 |
| AC frequency range (Hz) | 45-65Hz |
| Switchover time after grid disconnection (ms) | <500 |
| Rated AC power (W) | 6000 |
| Maximum continuous input current at 230 V (A) | 26,1 |
| Operation in backup power mode | |
| Rated AC power in continuous backup operation (W) | 6000 |
| Maximum continuous input current in backup mode (A) | 26,1 |
| Peak AC power in backup mode for <10 s (W) | 6600 |
| Peak AC current in backup mode for <10 s (A) | 28,7 |
| Communication and control | |
| Communication interface | RS485 |
| Manual bypass switch | Yes |
| Accuracy of the imported and exported energy meter (%) | 1 |
| Operating conditions | |
| Cooling | Natural convection |
| Noise level (dB) | <30 |
| Operating temperature range (°C) | -40~60 |
| Degree of protection | IP65 |
| Relative humidity during operation (%) | Up to 100 |
| Maximum height (m) | 3000 |
| Dimensions and weight | |
| Mounting method | On the wall |
| Weight (kg) | 11 |
| Dimensions (height/width/depth) (mm) | 365/450/123 |
