Battery module – FoxESS – CQ7-M – HV
SKU: CQ7-M
Product details
CQ7
CQ7 is a high-voltage energy storage system based on LFP (LiFePO4) batteries. Its modular design enables expansion by connecting additional batteries in series, up to a capacity of 98.28 kWh. Easy assembly reduces installation time.
Key benefits of CQ7
- Module with a capacity of 7.02 kWh forms the basis of a scalable system.
- Nominal capacity of the sets 14.04–98.28 kWh, depending on the configuration.
- Depth of discharge up to 100%.
- LFP (LiFePO4) technology in a high-voltage battery system.
- CAN communication.
Who is this a good choice for?
CQ7 is an option for users who need an energy storage system with a capacity tailored to their needs, as well as those planning to expand their system later. The modular design and the ability to connect batteries in series allow the capacity to be increased to 98.28 kWh.
Datasheet
Datasheet-CQ7-EN.pdf
| Parameter | CQ7-L2 | CQ7-L3 | CQ7-L4 | CQ7-L5 | CQ7-L6 | CQ7-L7 | CQ7-L8 | CQ7-L9 | CQ7-L10 | CQ7-L11 | CQ7-L12 | CQ7-L13 | CQ7-L14 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Operating characteristics | |||||||||||||
| Battery type | LFP (LiFePO4) | ||||||||||||
| Number of CQ7-M modules (pcs.) | 1 | ||||||||||||
| Number of CQ7-S modules (pcs.) | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 |
| Nominal capacity (kWh) | 14,04 | 21,06 | 28,08 | 35,10 | 42,12 | 49,14 | 56,16 | 63,18 | 70,20 | 77,22 | 84,24 | 91,26 | 98,28 |
| Usable capacity (kWh) | 14,04 | 21,06 | 28,08 | 35,10 | 42,12 | 49,14 | 56,16 | 63,18 | 70,20 | 77,22 | 84,24 | 91,26 | 98,28 |
