Solar cable – HELUKABEL – H1Z2Z2-K – 1x4mm2 – red – OUTLET

Cable type

SOLARFLEX®-X H1Z2Z2-K

Number of cores (part 1)

1 x

Cross-sectional area (part 1)

4 mm²

Cross-sectional area (part 1+2)

1 x 4 mm²

Cable specification

flame-retardant, halogen-free, UV-resistant

Outer diameter

5.4 mm

Color

red

Package contents

100 m

Rated voltage

1500 V

Nominal voltage U0

1000 V

Test voltage

6500 V

Insulation material

copolymer

Bending radius for rigid conductor

5

Halogen-free

yes

Shielded

no

Conductor construction

Stranded bare conductor, according to DIN VDE 0295 Cl.5, made of fine wires, BS6360 cl.

Minimum temperature range for fixed connections

-40 °C

Maximum temperature range for fixed connections

90 °C

RoHS compliant

Yes

Certificates, standards

EN 50618 TÜV Rheinland 2 PfG 1990/05.12 TÜV R60115689
