Inverter – FRONIUS – Symo GEN24 12.0 Plus SC – hybrid – HV
SKU: 4,210,189,002
EAN: 9007947582591
Product details
Symo GEN24 SC
Symo GEN24 SC is a three-phase photovoltaic inverter with a rated output power of 12 kW, equipped with two MPP trackers. The built-in PV Point function provides basic backup power, while open communication interfaces enable integration of components from Fronius and third-party suppliers. Active cooling extends the device’s service life.
Key benefits of Symo GEN24 SC
- Output power 12 kW and the option to connect a photovoltaic array with a maximum capacity of 18 kWp.
- Two MPP trackers with a usable voltage range of 80–800 V and maximum usable input currents of 28 A and 14 A.
- Basic backup power supply PV Point with a rated output power of 3000 VA, a single-phase 220/230 V output and a switching time of approximately 15 seconds.
- Maximum efficiency 98.2% and a European efficiency of 97.9%.
- WLAN communication, two Ethernet LAN ports and two RS485 interfaces and an integrated data logger and web server.
- IP66 protection rating and active cooling — installation inside and outside buildings and an ambient temperature range from -25 to +60°C.
Who is this a good choice for?
Symo GEN24 SC is an option for homeowners with a photovoltaic system who need basic PV Point backup power. It is also suitable for PV system users who want to integrate components from Fronius and third-party suppliers and access data through extensive communication interfaces.
Datasheet
Datasheet-GEN24-3.0-12.0-Plus-SC-EN.pdf
| Parameter | Fronius Symo GEN24 SC 12.0 | Fronius Symo GEN24 Plus SC 12.0 |
|---|---|---|
| DC input data | ||
| Number of MPP trackers | 2 | |
| DC input voltage range (V) | 80 - 1,000 | |
| Nominal input voltage (V) | 610 | |
| Start-up voltage (V) | 80 | |
| Usable MPP voltage range (V) | 80 - 800 | |
| MPP voltage range at rated power (V) | 295 - 800 | |
| Maximum total usable DC power (W) | 12,360 | |
| Maximum total PV generator power (Wpeak) | 18,000 | |
| MPPT 1 | ||
| Maximum usable input current MPPT 1 (A) | 28 | |
| Maximum PV generator short-circuit current MPPT 1 (A) | 40 | |
| Number of DC connections MPPT 1 | 2 | |
| Maximum usable DC power MPPT 1 (W) | 12,360 | |
| Maximum PV generator power MPPT 1 (Wpeak) | 14,000 | |
| MPPT 2 | ||
| Maximum usable input current MPPT 2 (A) | 14 | |
| Maximum PV generator short-circuit current MPPT 2 (A) | 20 | |
| Number of DC MPPT connections 2 | 1 | |
| Maximum usable DC power MPPT 2 (W) | 8,600 | |
| Maximum PV generator power MPPT 2 (Wpeak) | 9,000 | |
| AC output data | ||
| Rated AC output power (W) | 12,000 | |
| Apparent power (VA) | 12,000 | |
| Maximum output power (VA) | 12,000 | |
| Rated AC output current at 380 V (A) | 18,2 | |
| Rated AC output current at 400 V (A) | 17,4 | |
| Grid connection (V) | 3~ NPE 400/230 or 3~ NPE 380/220 (+20%/-30%) | |
| Rated frequency and frequency range (Hz) | 50/60 (45 - 65) | |
| Total harmonic distortion (%) | < 3,5 | |
| Power factor | 0.7 - 1 inductive / capacitive | |
| PV Point (Comfort) backup power supply | ||
| Rated output power (VA) | 3,000 | |
| Grid connection (V) | 1~ NPE 220/230 | |
| Switching time (s) | ~15 | ~10 |
| Full backup power (Full Backup) | ||
| Rated output power (VA) | 12,000 | |
| Grid connection (V) | 3~ NPE 400/230 or 3~ NPE 380/220 | |
| Switching time (s) | ~10 | |
| Energy storage | ||
| Number of DC inputs | 1 | |
| Maximum DC input current (A) | 22 | |
| DC input voltage range (V) | 160 - 700 | |
| DC battery connection technology | 1 push-in spring terminal each, 2.5–10 mm², BATT+ and BATT- | |
| Maximum DC input / output power (W) | 11,682 | |
| Maximum charging power via AC connector (W) | 11,682 | |
| Compatible batteries | Fronius Reserva & BYD Battery-Box Premium HVS/HVM & LG FLEX | |
| Efficiency | ||
| Maximum efficiency (%) | 98,2 | |
| European efficiency (%) | 97,9 | |
| MPP efficiency (%) | > 99,9 | |
| Nighttime power consumption (W) | <10 | |
| Dimensions and weight | ||
| Dimensions, height × width × depth (mm) | 595 × 529 × 180 | |
| Inverter weight (kg) | 22,8 | |
| Operating conditions | ||
| IP protection rating | IP 66 | |
| Protection class | 1 | |
| DC/AC overvoltage category | 2/3 | |
| Cooling | Active cooling technology | |
| Installation | Inside and outside buildings | |
| Ambient temperature range (°C) | -25 to +60 | |
| Permissible air humidity (%) | 0 - 100 | |
| Noise emission (dB(A)) | < 47 | |
| Maximum altitude above sea level (m) | 3000 / 4000 (unrestricted / restricted voltage range) | |
| Connections | ||
| PV DC connection technology | 3 push-in spring terminals 2.5–10 mm² DC+ and DC- | |
| AC connection technology | 5-pole push-in AC spring terminals 1.5–10 mm²; 3-pole push-in backup power spring terminals 1.5–10 mm²; 5 PE screw terminals 2.5–16 mm² | |
| Protection | ||
| DC insulation measurement | Integrated | |
| DC disconnector | Integrated | |
| Reverse polarity protection | Integrated | |
| WSD emergency shutdown | Integrated | |
| Communication and control | ||
| WLAN / 2 × Ethernet LAN | Fronius Solar.web, Modbus TCP SunSpec, Fronius Solar API (JSON) | |
| 6 digital inputs | Connection to remote control receiver, power management | |
| 6 digital inputs/outputs | Integrated | |
| Data logger and web server | Integrated | |
| 2 × RS485 | Modbus RTU SunSpec (third-party) / Fronius Smart Meter, battery, Fronius Ohmpilot | |
| Certificates | ||
| Certifications held and standards met | IEC 62109, IEC 62116, IEC 61727, IEC 62909, VDE AR-N4105, AS/NZS 4777.2, EN 50549, CEI 0-21, G 98, R25 | |
| Life cycle analysis | In accordance with ÖNORM EN ISO 14040 and 14044 (study conducted by staff of the Fraunhofer IZM institute) | |
Energy storage and Full Backup functions are available only with GEN24 Plus. Full Backup requires additional external switching components. Charging power and battery DC power depend on the connected battery; compatibility depends on its type, capacity class, certification and availability in the country concerned.
