Energy meter – SOLAREDGE – MTR-3Y-400V-A
| Manufacturer | |
|---|---|
| Warranty | |
| Net width | |
| Net depth | |
| Net height | |
| CN | 90283019 |
Incl. VAT
Complementary products
Product details
| Manufacturer | |
|---|---|
| Warranty | |
| Net width | |
| Net depth | |
| Net height | |
| CN | 90283019 |
SE-MTR-3Y-400V-A
SE-MTR-3Y-400V-A is an energy meter with a Modbus connection designed for SolarEdge installations. It provides high measurement accuracy when monitoring energy production and consumption, and the import and export readings enable limiting energy export. Its compact size and fit for standard electrical panels make installation easier.
Key advantages of the SE-MTR-3Y-400V-A
- Modbus connection for operation in SolarEdge installations.
- High measurement accuracy when monitoring energy production and consumption.
- Import and export energy readings supporting the export limiting functionality.
- Compact size and easy installation in standard electrical panels.
- Supports 120 ohm termination for RS-485.
- 5-year warranty.
Who is this a good choice for?
This solution is for owners of SolarEdge installations on residential buildings, companies using commercial installations, and operators of large photovoltaic power plants. It is suitable for customers who need accurate monitoring of energy production and consumption and import/export readings to limit energy export.
| Parameter | Value |
|---|---|
| General data | |
| Model | SE-MTR-3Y-400V-A |
| Communication | |
| Communication protocol | Modbus |
| Communication interface | RS-485 |
| Termination resistance (Ω) | 120 |
| Warranty | |
| Product warranty (years) | 5 |
(1) Protective earth (PE) is not required to operate the meter.; (2) The energy meter is intended for indoor use and is connected to multi-phase inverters using RS485.; (3) Use with model SE-ACTL-0750-CT.; (4) +/- 1.0% accuracy at 100% of the CTR current.; (5) +/- 1.5% accuracy for 1% to 99% of the CTR current.; (6) Accuracy complies with IEC 62053-22 Class 0.5S for 100% of the CTR current.
